Copper XLPE SWA PVC Cable
- 0.6/1kV · BS 5467 / IEC 60502-1
- Multi-core · Direct burial and industrial distribution
0.6/1kV Armoured Power Cable
Low Voltage Armoured Cable
0.6/1kV XLPE armoured power cables for direct burial, industrial distribution, building projects and EPC tenders. Available with copper or aluminum conductors, SWA or AWA armour, PVC or LSZH sheath.
- Copper & Aluminum Conductor Available
- SWA / AWA / STA / AIA Armour Options
- IEC / BS / ICEA / NFC / UNE / CSA
- Customized Cable Solutions for Electric Projects
Main Armoured Cable Range
Low Voltage Armoured Cable Range
Aluminum XLPE SWA PVC Cable
- 0.6/1kV · IEC 60502-1 / Project standard
- Multi-core · Long runs and cost-sensitive distribution
Single-Core XLPE AWA PVC Cable
- 0.6/1kV · BS 5467 / IEC 60502-1
- Single-core · AC feeders and main distribution
XLPE SWA LSZH Cable
- 0.6/1kV · BS 6724 / IEC 60502-1
- Multi-core · Buildings, tunnels and public works
Quotation Support
What You Receive with Your Quotation
Matched cable construction and applicable standard
Technical datasheet and cable dimensions
Packing and drum-length proposal
Lead time, shipping terms and support
Armour Selection
Which Armour Type Do You Need?
Not sure which construction matches your project? Send us the cable schedule for review.
Multi-core cables, underground and industrial routes
Typical constructionCu/XLPE/PVC/SWA/PVC
Single-core AC power cables
Typical constructionCu/XLPE/PVC/AWA/PVC
Fixed buried routes requiring compression protection
Typical constructionCu or Al/XLPE/STA/PVC
Typical Applications
Low Voltage Armoured Cable Applications
Underground Power Distribution
Buried feeders, trenches and outdoor cable routes.
Industrial Facilities
Power supply for motors, panels, pumps and workshops.
Commercial Buildings
Main LV distribution with PVC or LSZH sheath options.
Utility & Infrastructure Projects
Project supply for public works and distribution networks.
Have a Cable List or BOQ?
Send Your Cable Schedule for Review
Send voltage, size, standard, quantity and destination. Starsun can return a matched cable construction and quotation path.
Starsun Electric supplies 0.6/1kV armoured power cables for underground distribution, industrial facilities, commercial buildings and infrastructure projects. Available constructions include copper or aluminum conductors, SWA or AWA armour, and PVC or LSZH outer sheaths, manufactured according to IEC 60502-1, BS 5467, BS 6724 or project specifications.
Buyer Questions
Low Voltage Armoured Cable FAQ
Can low voltage armoured cable be directly buried?
Yes, armoured cables are commonly used in direct burial and cable trench routes when the selected construction, bedding, sheath and installation method meet the project conditions.
Should I choose SWA or AWA?
Multi-core LV cables commonly use steel wire armour. Single-core AC cables commonly use aluminum wire armour because it is non-magnetic and helps avoid heating caused by magnetic armour losses.
Can Starsun provide LSZH armoured cable?
Yes. LSZH sheath options can be supplied for building, tunnel, public infrastructure and fire-performance projects, commonly under BS 6724 or project specifications.
What information should I send for a fast quotation?
Send standard, voltage, conductor material, core number, cable size, armour type, sheath type, quantity, delivery destination and any required test reports or approvals.
